Borehole Pump Maintenance in Kenya: Why Pumps Fail Early and How to Prevent It

The call always arrives in the same shape. A borehole that has watered a home or a dairy for three seasons goes quiet, and by lunchtime somebody has quoted the owner for a new pump. Very often that pump is mechanically sound. What failed was a taped cable joint forty metres down, a control box with no proper overload, or a water level that dropped below the intake every dry afternoon for a month.

A submersible pump is unlike every other machine on a Kenyan farm because you cannot see it, hear it or touch it, and everything you can control sits at the surface. If you are still choosing, start with our guide to choosing a water pump and the comparison of a borehole against a shallow well. This article is about what happens after the installer drives away.

Most Submersible Pump Failures Are Not Pump Failures

There is remarkably little inside a borehole pump to go wrong: a stack of small impellers and diffusers, each adding a slice of pressure, above a sealed motor cooled by the water flowing past its shell into the intake. So when a decent pump dies young, the cause is usually external: the supply, the cable and joint carrying it down the hole, the water level it was asked to work in, or the sand it was asked to swallow. Diagnose in that order and you will be right far more often than the shop that reaches straight for a replacement.

It also defines a proper diagnosis. Before anyone condemns a pump, an electrician should test the supply voltage on each phase, insulation resistance to earth, winding balance and running current against the motor plate. Those readings separate a burnt motor from a wet joint in about twenty minutes.

Dry Running, and the Low Level Cut-Out That Prevents It

Dry running is the fastest way to destroy a submersible pump, and the least visible. The motor is cooled almost entirely by borehole water moving past its shell, so take that flow away and winding temperature climbs within minutes: insulation cooks, the thrust bearing loses the water film it slides on, and the motor either burns out or quietly loses years of life.

The damaging version is rarely one dramatic event. It is repetition. A borehole pumped harder in a dry February drops to the intake for the last ten minutes of every run, nobody notices anything except slower filling, and six weeks of that will finish a motor.

The protection is cheap relative to the pump. A low level cut-out senses when water has fallen to a set point safely above the intake, stops the motor, and restarts only once the column has recovered. It may be electrode probes hung in the hole, a level sensor in the control box, or a dry-run relay watching motor current. Pair it with a level switch in the storage tank, so the pump runs only when there is water below it and space above it.

Size to Yield and Drawdown, Not to Depth

Three numbers govern a borehole. The static water level is where water rests when the pump is off, the pumping level is where it settles while the pump works, and the gap between them is drawdown. The rate the hole can be pumped indefinitely without drawdown running away is its yield. Your driller measured all of it during test pumping and wrote it into the completion report, with a recommended pumping rate and setting depth. Keep a copy: it is the most valuable maintenance document you own.

Oversizing is the common error. A bigger pump feels like more water, so the buyer takes the next size up. In a hole of modest yield that pump drags the level to the intake within an hour and cycles on its dry-run protection. The aquifer, not the motor, sets how much water is available: if you need more litres per day, run a correctly sized pump longer into storage.

Storage is therefore part of pump protection. It is also why solar borehole pumping suits so many Kenyan sites: solar pumps slowly across a long day into a tank, which is what a borehole prefers.

Sand and Abrasion: The Slow Grind

Sand comes from an incompletely developed hole, a worn screen, or a pump pulling harder than the aquifer can supply. Once circulating it behaves like a lapping compound: it rounds off impeller vanes and opens the clearances inside each stage, so the pump makes less pressure for the same power, and heavy sand can settle around the motor and choke its cooling. It shows up as grit in the tank, clogged drip lines and slower filling.

The fix is upstream: the pump belongs above the screened section, the pumping rate should come back to the tested figure, and where sand persists the driller should be asked about re-developing the hole. Surface separators protect your plumbing, but they do nothing for the pump.

Cable and Joints: Why a Cheap Splice Pulls More Pumps Than Anything Else

Submersible drop cable is designed for permanent immersion, and two things about it decide whether your pump survives. The first is the splice. Every installation joins the motor lead to the drop cable, and that joint spends its life under water pressure. Done properly it uses a heat-shrink or resin kit that seals each conductor and then the whole bundle. Done with insulation tape, it leaks: water tracks along the copper, insulation resistance collapses, earth leakage protection starts tripping, and the motor burns. It is the commonest reason a good pump gets pulled.

The second is cable size. Over a long drop an undersized conductor loses voltage, so the motor draws more current for the same work and runs hotter. Sizing is a calculation involving run length, motor current and permitted voltage drop, not a matter of fitting whatever is in the van. The cable should also be clipped to the riser so it cannot chafe against the casing.

The Control Box Is Your Insurance Policy

The control box is where protection actually lives: a contactor, a thermal overload set to the motor plate current, a run capacitor on single-phase units, and relays whose purpose is to stop the pump before something expensive happens.

The ones worth paying for are undervoltage and overvoltage, for a supply that sags or spikes; phase failure and imbalance protection on three-phase systems, because single-phasing cooks a motor quickly and quietly; overload matched to the actual motor; dry-run protection; and surge protection with sound earthing, which matters on exposed rural feeders where lightning is a recurring cause of pump loss. Where the box lives matters too: dry, shaded, ventilated, lockable, sealed against ants and rodents.

Treat a trip as information. A device that keeps operating is telling you something about the supply, the water level or the pump, and winding an overload up converts a warning into a burnt motor.

Monitor Flow and Pressure, and Keep a Log

Nearly every borehole failure gives weeks of warning in two numbers: how much water arrives, and at what pressure. The trick is having last month's figures to compare against.

The measurement is simple. Time how long the pump takes to fill a 20 litre jerrican from a fixed outlet, and note the pressure gauge while it does, on the same day each month. Flow that drifts down while pressure holds points to worn stages, a partly blocked intake or a falling water level; a sudden drop points to a fault. Watch the cycling too: a pump starting every few seconds is usually running on a pressure tank that has lost its air charge, and every start draws heavy current.

Once a year, have a technician measure running current on each phase and insulation resistance to earth. Rising current suggests drag from bearings or sand; falling current with falling flow suggests worn hydraulics. Insulation resistance sliding down over successive readings is the clearest early warning of a failing cable joint you will get.

The log itself can be a school exercise book on a nail: date, run hours, litres per minute, pressure, anything unusual, plus every service event, the setting depth and the cable size. Diagnosis at a borehole with a log takes an hour instead of a day.

Scale, Iron and Fouling

Water chemistry does its damage slowly. Hard water deposits calcium carbonate on every surface it touches, narrowing screen slots and building up in the passages between impeller and diffuser. Water carrying dissolved iron and manganese, common in parts of Kenya, supports bacteria that produce a reddish-brown slime called ochre, which blocks screens, non-return valves and drip emitters.

The signs are brown staining on sanitary ware, a metallic smell, slime in the storage tank, and flow declining steadily over a year. Get a water analysis before buying any treatment, because filtration, softening, oxidation and dosing target different problems. Where fouling is established in the hole itself, rehabilitation is a job for the drilling contractor.

When to Pull a Pump, and What to Inspect While It Is Out

Pulling a submersible pump is not routine and should never be done speculatively. It is justified when there is no delivery with supply and control confirmed healthy, when protection trips repeatedly, when insulation resistance has fallen below the manufacturer's minimum, when sand output is heavy, or when flow has fallen far below the original figure at an unchanged water level.

The removal itself is a rigging operation. Pump, motor, riser and the water inside weigh a great deal, the assembly is under tension, and a pump dropped down a borehole is frequently unrecoverable. This is work for your driller or a competent pump contractor with a tripod, a winch and proper lifting clamps, and the electrical reconnection afterwards belongs to a qualified electrician.

Insist on a proper inspection while the pump is on the surface, and a written record of it: the cable jacket examined and the splice cut open; insulation resistance and winding balance measured on the bench; the shaft turned by hand for roughness and end float; the wet end opened to check impeller wear and sand packing; the intake screen, non-return valve and safety rope checked; and the setting depth measured.

Those findings decide the real question, repair against replace. A motor with sound windings and a worn wet end is often worth rebuilding; one cooked by dry running rarely repays a rewind. Either way, the moment the pump is out is your one chance to fix the underlying cause: upgrade the splice, correct the cable size, reset the depth from the driller's report, and fit the protection that should have been there from the start. Talk to us about the pumps and control gear in our water equipment range, and see indicative figures on the price list.
